Large Boat Ramp Systems
Premium Roll-N-Go Ramps
Our custom large boat ramps are engineered for vessels over 4,200 lbs.
Each system is tailored to your specific requirements - connect with our sales team to design the perfect solution.
Large Boat
Filters
1 item
FILTER BY:
SPECS
1000
1500
2000
PONTOON
Max Weight Capacity
1,000 lbs.
1,500 lbs.
2,000 lbs.
2,000 lbs.
Weight
90 lbs
120 lbs
155 lbs
250 lbs
Overall Length
16'
16'
16'
16'
Overall Width
Adjustable
Adjustable 22″-39″
Adjustable 33″-49"
Adjustable*
Track Width
Adjustable 22″-32″
Adjustable 22″-32″
Adjustable 24″-40"
Adjustable*
Roller Type
1.5″ Width X 3.5″ Diameter
3.5″ Width X 5″ Diameter
3.5″ Width X 5″ Diameter
1.5″ Width X 3.5″ Diameter
# of Rollers
12
16
24
52
Tilting Roller Axle
N/A
Yes
Yes
N/A
Construction
Aluminum
Aluminum
Aluminum
Aluminum
Hardware
Stainless Steel
Stainless Steel
Stainless Steel
Stainless Steel
Winch
Zinc Plated
Zinc Plated
Zinc Plated
Zinc Plated
Dead Lift Rating
1,100 lbs.
1,100 lbs.
1,600 lbs.
1,600 lbs.
Strap Length
30′
30′
30′
30′
Hook Type
Standard Boat Hook
Standard Boat Hook
Standard Boat Hook
Standard Boat Hook
Anchoring
See Below
See Below
Screw-in Ground Anchor
Screw-in Ground Anchor
1000
Max Weight Capacity
1,000 lbs.
Weight
90 lbs
Overall Length
16'
Overall Width
Adjustable
Track Width
Adjustable 22″-32″
Roller Type
1.5″ Width X 3.5″ Diameter
# of Rollers
12
Tilting Roller Axle
N/A
Construction
Aluminum
Hardware
Stainless Steel
Winch
Zinc Plated
Dead Lift Rating
1,100 lbs.
Strap Length
30′
Hook Type
Standard Boat Hook
Anchoring
See Below
1500
Max Weight Capacity
1,500 lbs.
Weight
120 lbs
Overall Length
16'
Overall Width
Adjustable 22″-39″
Track Width
Adjustable 22″-32″
Roller Type
3.5″ Width X 5″ Diameter
# of Rollers
16
Tilting Roller Axle
Yes
Construction
Aluminum
Hardware
Stainless Steel
Winch
Zinc Plated
Dead Lift Rating
1,100 lbs.
Strap Length
30′
Hook Type
Standard Boat Hook
Anchoring
See Below
2000
Max Weight Capacity
2,000 lbs.
Weight
155 lbs
Overall Length
16'
Overall Width
Adjustable 33″-49"
Track Width
Adjustable 24″-40"
Roller Type
3.5″ Width X 5″ Diameter
# of Rollers
24
Tilting Roller Axle
Yes
Construction
Aluminum
Hardware
Stainless Steel
Winch
Zinc Plated
Dead Lift Rating
1,600 lbs.
Strap Length
30′
Hook Type
Standard Boat Hook
Anchoring
Screw-in Ground Anchor
PONTOON
Max Weight Capacity
2,000 lbs.
Weight
250 lbs
Overall Length
16'
Overall Width
Adjustable*
Track Width
Adjustable*
Roller Type
1.5″ Width X 3.5″ Diameter
# of Rollers
52
Tilting Roller Axle
N/A
Construction
Aluminum
Hardware
Stainless Steel
Winch
Zinc Plated
Dead Lift Rating
1,600 lbs.
Strap Length
30′
Hook Type
Standard Boat Hook
Anchoring
Screw-in Ground Anchor
OPTIONS
Extension Sections
8′ & 4′
8′ & 4′
8′ & 4′
8′
Anchoring Recommended
w/ steeper slope or extensions
w/ steeper slope or extensions
Included in Kit
Included in Kit
Winch Upgrade Available
N/A
1,500-lb.self-braking w/ 50′ cable
1,500-lb.self-braking w/ 50′ cable
1,500-lb.self-braking w/ 50′ cable
Support Leg Kit
Yes
Yes
Yes
Yes
Wide Support Kit
Yes
Yes
Yes
Yes
Float Kit
Yes
Yes
Yes
N/A
